MAC-10

The MAC-10 (Military Armament Corporation Model 10, officially the M-10) is a compact, blowback operated machine pistol developed by Gordon B. Ingram in 1964. It is chambered in either .45 ACP or 9mm. A two-stage suppressor by Sionics was designed for the MAC-10, which not only abated the noise created, but made it easier to control on full automatic (although it also made the gun far less compact and concealable). The MAC-10 was designed to fill the role of a compact, cheap-to-produce submachine gun/personal defense weapon. To this end, the MAC-10 is built predominately of sheet steel stampings. A notched cocking handle protrudes from the top of the receiver, and turning the handle 90° locks the bolt, and acts as an indicator the weapon is unable to fire. The M10 has a telescoping bolt, which wraps around the rear face of the barrel. This allows a more compact weapon and balances the weight of the weapon over the pistol grip, where the magazine is located. The M10 fires from an open bolt, and the light weight of the bolt results in a rapid rate of fire. In addition, this design incorporates a built in feed ramp as part of the trigger guard (a new concept at the time) and to save on cost the magazine was recycled from the M3 Grease Gun. The barrel is threaded to accept a suppressor, which works by reducing the discharge's sound without attempting to reduce the speed of the bullet. This works well with the .45 ACP versions, as most loads are subsonic already, as opposed to special, low-powered subsonic loads usually required for suppressed 9mm weapons. At the suggestion of the United States Army, the suppressor also acts as a foregrip to inhibit muzzle rise when fired. Ingram added a small bracket with a small strap beneath the muzzle to aid in controlling recoil during fully automatic fire. The primary reason for the original M10 finding recognition was its revolutionary sound suppressor designed by Mitchell WerBell III of Sionics. This suppressor has a two-stage design, with the first stage being larger than the second. This uniquely shaped suppressor gives the MAC-10 a very distinctive look. It is also very quiet, to the point that the bolt can be heard cycling, along with the suppressed report of the weapon's discharge, though only if subsonic rounds are used (standard .45 ACP rounds are subsonic). The suppressor, when used with a Nomex cover, creates a place to hold the firearm with the secondary hand, making it easier to control. During the 1970s, the United States placed restrictions on the export of suppressors, and a number of countries canceled their orders as the effectiveness of the MAC-10's suppressor was one of its main selling points. This was one factor that led to the bankruptcy of Military Armament Corporation, another being the company's failure to recognize the private market. The original Sionics suppressor is 11.44 inches in length, 2.13 inches in overall diameter, and weighs 1.20 pounds.
