Takao

The Takao-class cruisers were an improved version of the previous Myōkō-class design, incorporating technical elements learned with the development of the experimental light cruiser Yūbari. They had a distinctive profile with a large, raked main smokestack, and a smaller, straight, second smokestack. Intended to address issues with the Myōkō class, the Takao class had thicker armor, dual-purpose main guns which could be used against aircraft, and torpedo launchers moved to the upper deck for greater safety. However, as with its predecessors, the Takao class was also top-heavy. The Takao class displaced 16,875 t (16,608 long tons). Takao was 203.8 metres (669 ft) long, with a beam of 20.4 metres (67 ft), draft of 6.32 metres (20.7 ft) and were capable of 35.25 knots. Propulsion was by 12 Kampon boilers driving four sets of single-impulse geared turbine engines, with four shafts turning three-bladed propellers. The ship was armored with a 127 mm (5 in) side belt, and 35 mm (1 in) armored deck; the bridge was armored with 10 to 16 mm (0.39 to 0.63 in) armored plates. Takao’s main battery was ten 20 cm/50 3rd Year Type naval guns, the heaviest armament of any heavy cruiser in the world at the time, mounted in five twin turrets. Her secondary armament included eight Type 10 12cm dual purpose guns in four twin mounts on each side, and 16 Type 90 torpedoes in four quadruple launchers. She was very deficient in anti-aircraft capability, with only two 40 mm (1.57 in) anti-aircraft guns. Takao was repeatedly modernized and upgraded throughout her career in order to counter the growing threat of air strikes, and in her final configuration was armed with ten Type 3 20 cm naval guns, ten 20 cm/50 3rd Year Type naval guns (5x2), four Type 89 12.7 cm (5 in) dual purpose guns, (4x2), and 16 Type 93 Long Lance torpedoes in four quadruple launchers (plus 8 reloads). Anti-aircraft protection included 24 triple-mount and 12 twin-mount and 26 single-mount Type 96 25 mm AT/AA Guns and four 13.2 mm AA machine guns.
